同用数量终端服务器关键性代替各大纸材，纸塑黏结类，膜类等装潢資料和内包装資料的复卷。

卡能及独特 1.超声波焊接机宽容步进驱动器定长上料，在高程序运行中始终高导致精度。2.PLC触控屏积极计米，米数积极控制在。3.自动式拒绝送料，收、放护符配气胀轴。4.积极切割、智泊之后随随便便设置，预送推算收秘药再持继收料等功能主治。Scope of applicationScope of applicationThis machine is mainly used for re-winding of various paper, paper-plastic composite, film and other decorative materials and packaging materials.

Performance and characteristics1. This machine adopts servo fixed length feeding to maintain high precision during high speed operation.2. PLC touch screen automatically counts meters, meters are automatically set.3. Pneumatic automatic feeding, receiving and discharging reels with air expansion shaft.4. Automatic cutting, free parking time setting, pre-feeding to rewind and continue to receive materials.

首要手艺参数 Main Technical Parameters

手机型号 Model		CLFJ-B800	CLFJ- B1000	CLFJ-B1300
自粘卷材长宽比 MAX.Parent Web Width		800mm	1000mm	1300mm
放卷尺寸 Max.parent Web Diameter		Φ600mm	Φ600mm	Φ600mm
收卷口径 Max.Rewinding Diameter		Φ300mm	Φ300mm	Φ300mm
浓度 Max.Machine Speed		10-180m/min	10-180m/min	10-180m/min
定长精密度较Fixed length accuracy		±5mm	±5mm	±5mm
总工作电压 Total Power		2.3KW	3KW	4.5KW
参量 Machine Weight		1000kg	1200kg	1500kg
图案尺寸大小 Overall Dimensions 任務电流电压 Working Voltage		2600×2000×1600mm 二相220V50HZ	2600×2200×1600mm 二相220V50HZ	2600×2500×1600mm 三相380V50HZ
纸芯型号Paper core specification	25mm, 38mm,50mm等 (or according to your requirement)
