配伍建设规模 :这手机重要适用于几大类纸制品，无纺织布，纸塑分手后复合类，无球膜类等装潢信息和彩盒信息的修边复卷。

机转及特色文化 :1.该机敞开心扉步进驱动器定长放卷，在稳定执行中坚定不移高准确度。2.PLC触感屏活跃的计米，米数活跃的快速设置。3.气动系统式分手后装料，收、放护符配气胀轴。4.自觉弄断、驻车时简静调整，预送推断收护符再持续时间收料等作用与功效。5.圆刀修边模切Scope of applicationThis machine is mainly used for re-winding of various paper, paper-plastic composite, film and other decorative materials and packaging materials.

Performance and characteristics1. This machine adopts servo fixed length feeding to maintain high precision during high speed operation.2. PLC touch screen automatically counts meters, meters are automatically set.3. Pneumatic automatic feeding, receiving and discharging reels with air expansion shaft.4. Automatic cutting, free parking time setting, pre-feeding to rewind and continue to receive materials.5. Round knife trimming and cutting

重中之重技术产品参数 : Main Technical Parameters

手机型号 Model		CLFJ- B1400	CLFJ-B1600
防水卷材长宽 MAX.Parent Web Width		1300mm	1500mm
放卷的直径 Max.parent Web Diameter		Φ1200mm	Φ1200mm
收卷口径 Max.Rewinding Diameter		Φ500mm	Φ500mm
传输速率 Max.Machine Speed		10-180m/min	10-180m/min
定长定位精度Fixed length accuracy		±5mm
总输出功率 Total Power		4.5KW	4.5KW
净重 Machine Weight		1300kg	1500kg
外观宽度 Overall Dimensions 任何电阻值 Working Voltage		2600×2200×1600mm 三相320V50HZ	2800×2500×1600mm 三相380V50HZ
纸芯规格型号Paper core specification	25mm, 38mm,50mm等 (or according to your requirement)
